Agilent Manual Injection Valve 7725i, 5067-4191 (New)

Agilent Manual Injection Valve 7725i (P/N 5067-4191) is a robust manual injection valve designed for HPLC systems equipped with the Agilent G1328C manual injector. The two-position, six-port valve provides reliable and highly reproducible sample injection at pressures up to 600 bar, making it a proven solution for routine analytical and method development applications.

Manufactured from high-quality stainless steel, the valve features integrated position sensing switches that enable monitoring of the valve position and seamless integration with chromatographic systems. Based on the proven Rheodyne 7725i design, the valve offers exceptional durability, mechanical reliability, and low maintenance requirements.

Key Features

• Manual 7725i injection valve for HPLC systems
• Two-position / six-port configuration
• Maximum operating pressure up to 600 bar
• Integrated position sensing switches
• Compatible with the Agilent G1328C Manual Injector
• Robust stainless-steel construction
• Highly reproducible sample injections
• Long service life with minimal maintenance requirements
• Suitable for routine analytical and research LC applications

Technical Specifications

• Product: Manual Injection Valve 7725i
• Part Number: 5067-4191
• Valve Type: Manual injection valve
• Configuration: 2-position / 6-port
• Maximum Pressure: 600 bar
• Material: Stainless steel
• Position Sensing Switches: Yes
• Compatibility: Agilent G1328C Manual Injector
• Technique: Liquid Chromatography (LC/HPLC)
• Application: Analytical applications
