Organomation RapidVap Vertex Dry Evaporator

The RapidVap Vertex Dry Evaporator accelerates sample evaporation by combining efficient dry heat with gentle nitrogen blowdown, allowing laboratories to process up to 50 samples simultaneously.

Its intuitive touchpad interface makes it easy to set and control both temperature and run time, and users can save up to ten custom programs to ensure consistent, repeatable workflows. Because it relies on a dry block heater rather than a traditional water bath, the system requires minimal upkeep—no distilled water, additives, or concerns about waterborne contamination.

The RapidVap Vertex is well-suited for a wide range of sample prep needs, including pharmaceutical and drug development, clinical laboratories, environmental analysis, agricultural chemistry, and forensic testing.

• LCD Display: Touchscreen programming shows parameters for block, sample, and time
• Nitrogen Control: Each switch controls nitrogen flow to each row of five nozzles
• Temperature Sensor: Monitors block or sample temperature
• Dry heat - no water bath: Less maintenance, no rust, no condensation, and no potential source of cross contamination

Organomation RapidVap Vertex Dry Evaporator

In partnership with Labconco.

STANDARD FEATURES

• LCD display with touchscreen programming
• Nitrogen control to each row of nozzles
• Pressure regulator for 0 to 45 psi
• Dry heat for less maintenance and no rust compared to water baths
• Microprocessor-controlled heater up to 100 °C
• Temperature sensor monitors block or sample temperature
• Angled samples to increase surface area for faster evaporation

REQUIREMENTS (not included)

• Aluminum block (Specific cat # depends on your tube size)
• Sample tubes
• Nitrogen source with a flow rate of 6.5 CFM/185 LPM minimum

SPECIFICATIONS

• Instrument Catalog Number: LC-7320020
• Bath Type: Dry aluminum blocks
• Number of Sample Positions: Up to 50
• Dimensions (w x d x h): 20.4 x 13.0 x 12.5 in
• Weight: Net: 35 lbs. (16 kg)
• Weight: Gross: 45 lbs. (20 kg)
• Sample Layout: 5 rows of 10 samples
• Lid Material: Glass
• Pressure Regulator: 0–45 psi
• Temperature Range: 30–100 °C
• Warranty: 1 year
• Electrical Requirements: 115V, 60 Hz

Nitrogen Requirements

• Flow Rate: 6.5 CFM / 185 LPM minimum
• Pressure: <50 psi

ACCESSORIES

• Aluminum blocks
