Watrex xTrovert XT Automatic DNA/RNA extractor

Automatic extractor utilises a simple principle of two pipetting heads serving a 96-well plate.

Thanks to easy replacement head options of pipetting with 300 μl tips or 1000 μl tips are available. Automatic optical sensor calibration enables the use of pipetting tips and 96-well plates from virtually any supplier. The device is equipped with two magnetic arms for protocols including paramagnetic SPR beads. It also allows for thermal incubation in the range of 25 to 85 °C. In addition to internal LED lighting, the station is equipped with an integrated UV-C sterilisation unit. Intuitive control from TFT touch panel user interface facilitates easy set-up. xTrovert™ XT is a fully programmable open system where user can create their own workflow scripts downloadable as text files from USB flas disk.

APPLICATIONS

• Sample prep for PCR testing
• NGS library prep
• Sanger DNA sequencing

CURRENT PROTOCOLS

• DNA/RNA extraction
• DNA purification
• PCR clean-up/desalting

Watrex: Watrex xTrovert XT Automatic DNA/RNA extractor - Compatible with any magnetic bead based kit

TECHNICAL SPECIFICATION

• Capacity: 16 or 32 samples/run
• Volume range: 10 – 600 μl
• Temperature: 25 – 85 °C
• Sterilization: UV-C
• Display: 3,5“ TFT touch display
• Connectivity: USB 1.0/2.0
• Power source: 24 V adaptor
• Dimensions in cm: 65(w) x 65(h) x 34(d)
• Weight: 25 kg

Ordering information:

PN/Component:

• XTR000-001 xTrovert™ XT Universal robotic pipettor for DNA/RNA extraction & handling
• XTR000-003 Replaceable 8-channel 1000uL pipetting head for xTrovert™ XT
• XTR000-004 Replaceable 8-channel 300uL pipetting head for xTrovert™ XT
• XTR000-100 Deepwell plates (empty) for xTrovert™ XT
• XTR000-220 DNA/RNA extraction kit, mgn. beads, 16-rxns per plate

The entire system was designed and developed by Watrex Praha and is manufactured in the Czech Republic and promises a shift in the performance and efficiency of laboratory processes worldwide!

You can also visit this product on the Watrex website.
