Organomation RapidVap N2/48 Nitrogen Evaporator

The RapidVap N₂/48 Evaporation System combines nitrogen blowdown, vortex motion, and controlled heat to accelerate evaporation of up to 48 small samples or eight 450 mL samples simultaneously. A stream of nitrogen or dry gas reduces the partial pressure over the liquid, speeding solvent removal, while microprocessor-controlled vortex motion increases surface area and continuously mixes samples for maximum recovery.

Nitrogen delivery can be applied to 2, 4, 6, or all 8 clusters of six ports, conserving gas when processing fewer samples. Using a dry block heating method, the RapidVap N₂/48 offers a reliable, low-maintenance alternative to water bath systems and is ideal for applications such as drug development, bioresearch, combinatorial chemistry, environmental testing, forensics, and toxicology.

• Dry Block: Dry heating system prevents potential contamination source
• Increased Surface Area: Vortex motion increases surface area for faster evaporation
• PTFE-Coated Chamber: Aluminum with PTFE coating for broad range of chemical compatibility
• End-Point Detection: Signal completion of run allows samples to be left unattended while drying to desired end point

In partnership with Labconco.

Organomation RapidVap N2_48 Nitrogen Evaporator

STANDARD FEATURES

• Dry block heating system prevents adding potential contamination source
• Vortex action, heat, and vacuum combine to accelerate evaporation
• PTFE-coated chamber for broad range of chemical compatibility
• Microprocessor-controlled vortex motion increases surface area for faster evaporation
• Signal completion of run allows samples to be left unattended while evaporation to desired end point
• Microprocessor-controlled nitrogen blow down manifold to facilitate liquid to gas phase change

REQUIREMENTS (not included)

• Sample block
• Glassware
• Nitrogen source with flow rate of 3.5 CFM/100 LPM minimu
• Gas pressure regulator

OPTIONS

• RS-232 Link for two-way communication (Cat# LC-7910014)

SPECIFICATIONS

• Instrument: RapidVap N2/48
• Instrument Catalog Number: LC-7910012
• Bath Type: Dry aluminum blocks
• Number of Sample Positions: Up to 48
• Dimensions (w x d x h): 21.7 x 19.0 x 13.5 in
• Weight: Net: 92 lbs. (42 kg)
• Weight: Gross: 100 lbs. (45 kg)
• Sample Layout: Circular
• Lid Material: Glass
• Pressure Regulator: 0–20 psi
• Temperature Range: 0–100 °C
• Warranty: 1 year
• Electrical Requirements: 115V, 60 Hz
• Vortex Motion: Up to 500 RPM

Nitrogen Requirements

• Flow Rate: 3,5 CFM / 100 LPM minimum
• Pressure: 5–10 psi

ACCESSORIES

• PTFE-coated aluminum blocks
• Borosilicate glass tubes
• 600 mL tubes with stems
• 170 mL tubes with stems
• Flat bottom tubes
• Eight-place stainless steel racks
• Glassware caps
